surge protector DS134RS-230/G Type 1+2 AC 230/400 V 3-phase+N
Price Excl. Tax
Shipping & Tax calculated at checkout
Article Number: 14999162
|
SPD type
|
1+2 | |
|
Network
|
230/400 V 3-phase+N | |
|
AC system
|
TT-TNS | |
|
Nominal line voltage
|
Un | 230 Vac |
|
Temporary Over Voltage (TOV) Characteristics - 5 sec. Without disconnection
|
UT | 335 Vac withstand |
|
Temporary Over Voltage (TOV) Characteristics - 120 mn Without disconnection or with safety disconnection
|
UT | 440 Vac disconnection |
|
Temporary Over Voltage N/PE (TOV HT)
Without disconnection or with safety disconnection
|
UT | 1200 V/300A/200 ms withstand |
|
Operating current
Continious current at Uc
|
Ic | None |
|
Follow current
|
If | None |
|
Nominal discharge current
15 x 8/20 µs impulses
|
In | 20 kA |
|
Max. discharge current
max. withstand @ 8/20 µs by pole
|
Imax | 50 kA |
|
Impulse current by pole
max. withstand 10/350µs by pole
|
Iimp | 12.5 kA |
|
Total lightning current
max. total withstand @ 10/350µs
|
Itotal | 50 kA |
|
Withstand on overvoltages IEEE C62.41.1
|
20 kV | |
|
Specific energy by pole
max. withstand 10/350 µs
|
W/R | 40 kJ/ohm |
|
Connection mode(s)
|
L/N and N/PE | |
|
Protection mode(s)
|
Common/Differential mode | |
|
Protection level L/N
@ In (8/20µs)
|
Up L/N | 1.3 kV |
|
Protection level N/PE
@ In (8/20µs)
|
Up N/PE | 1.5 kV |
|
Admissible short-circuit current
|
Isccr | 25 000 A |
Product Description
The DS130R is an extreme duty Type 1+2 designed to protect the entrance of the electrical installation. The DS130R is a one-pole SPD and can be used in common mode or common and differential mode. DS130R AC surge protectors are designed to be connected in multi-pole configuration to protect single-phase, 3-phase and 3-phase+neutral AC networks. This SPD is DIN rail compatible.
